Annovi Reverberi – 2 Diaphragm Pump 19.6 gpm – AR70
$1,136.47
9910-D70
Stock levels may vary. Please contact us directly to confirm availability before placing your order.
Description
9910-D70 Series – Epoxy Coated 2 Diaphragm Pumps
These 2 diaphragm, epoxy-coated pumps achieve up to 19 gpm (71.8 lpm) and 290 psi (20 bar). This series includes models 9910-D70 and 9910-D70-HYD.
Pentair Hypro low pressure diaphragm pumps are recommended for ground and low-level spraying of herbicides, pesticides, liquid fertilizers and many other hard-to-handle fluids.
Low-cost maintenance and almost wear-free operation make these pumps ideal for a wide variety of spraying jobs. Pressure and output are designed for optimum performance of medium to large sized sprayers. These low pressure diaphragm pumps can be adapted for splined shaft, hollow shaft, and solid shaft drive options. Pumps include a pulsation dampener.
KEY FEATURES
Performance Information
Max. flow: 19 gpm/71.8 lpm
Max. pressure: 290 psi/20 bar
Max. rated speed: 550 rpm (D70); 3600 rpm (D70GR)
Max. fluid temperature: 140°F/60°C
Other Attributes
Port sizes: 1-1⁄4″ HB inlet, 1″ HB outlet
Shaft (D70): Select shaft kit for desired drive (see related products)
Pump shaft rotation: CW and CCW
Housing components for liquid handling: epoxy-coated
Diaphragms: 2, semi-hydraulic
Weight: 22 lbs./10 kg (D70); 31 lbs./14 kg (D70GR)
Additional information
| Weight | 22 lbs |
|---|---|
| Dimensions | 1 × 1 × 1 in |
