9910-D252GRGI

Description

9910-D252 Series – Anodized Aluminum 2 Diaphragm Pumps
These 2 diaphragm, anodized aluminum pumps achieve up to 6 gpm (22.7 lpm) and 290 psi (20 bar). This series includes models 9910-D252, 9910-D252GRGI & 9910-D252GRGI58.

Pentair Hypro medium pressure diaphragm pumps are recommended for spraying herbicides, pesticides, liquid fertilizers, and many other hard-to-handle fluids. Low-cost maintenance and almost wear-free operation make these pumps ideal for a wide variety of spraying jobs. Pressure and output are designed for optimum performance of small to medium-sized sprayers. Pentair Hypro medium pressure diaphragm pumps can be adapted for male 1-3/8″ splined shaft, female 1-3/8″ splined shaft, 1″ solid shaft, or gear reduction drive options. Pumps include a pulsation dampener.

KEY FEATURES
Port sizes: 3⁄4″ HB inlet, 1⁄2″ NPT outlet (D252); 3⁄8″ HB outlet (all gear reduction models)
Shaft (D252): 3⁄4″ solid keyed
Shaft (D252GRGI): 3⁄4″ hollow shaft with gear reduction for 2 to 3-1/2 hp gasoline engine
Shaft (D252GRGI58): 5⁄8″ hollow shaft with gear reduction for 2 to 3-1/2 hp gasoline engine
Shaft (D252GRGIAP): 3/4″ hollow shaft with a 5⁄8″ output shaft and gear reduction for 3 hp gasoline engine
Diaphragms: 2, semi-hydraulic
Mounting base included
Crankcase Oil Capacity: 13 oz.
MATERIALS

Housing: anodized aluminum
MAXIMUM FLOW: 6 gpm/22.7 lpm

MAXIMUM PRESSURE: 290 psi/20 bar

MAXIMUM RATED SPEED: 650 rpm (D252); 3600 rpm (D252GRGI, D252GRGIAP and D252GRGI58)

MAXIMUM FLUID TEMPERATURE: 140°F/60°C

WEIGHT: 12 lbs./5.4 kg (D252); 14 lbs./6.4 kg (all gear reduction models)
